Chicago Pneumatic T250-7, 250 cfm Skid Mounted Diesel Air Compressor
For maximum airflow in a truck-mounted package, the Chicago Pneumatic T250-7 stands out. Delivering 250 CFM at 7 bar (100 PSI), it’s built to power large-scale tools, multiple operators, and demanding site work — all without compromising truck space.
Designed for permanent installation on service trucks or trailers, this heavy-duty skid-mounted compressor features a reliable Kubota diesel engine, compact profile, and stackable design for the most efficient use of space.
Add in single-side service access, and you’ve got a low-hassle, high-output air solution that’s built to go where your crew goes for projects across Perth and Western Australia.
Key Features
- High output: 250 CFM at 7 bar
- Skid-mounted for truck or trailer installation
- Powerful Kubota diesel performance
- Compact, stackable design for maximum efficiency
- One-sided servicing for quick access
When you need serious air power on the move, choose the T250-7.
Specifications
Model | T250-7 |
|---|---|
Normal effective working pressure (bar (psi)) | 7(100) |
Free air delivery (l/s) | 120 |
Free air delivery (cfm) | 250 |
Free air delivery (m3/min) | 7.1 |
Max. ambient temperature at sea level (°C) | 50 |
Min. starting temperature (°C) | -10 |
Min. starting temperature (Cold Start Aid) (°C) | -20 |
Engine | – |
Model | Kubota V2403T |
Number of cylinders | 4 |
Power output @ normal shaft speed (kW) | 47.9 |
Full load RPM (rpm) | 2700 |
Unload RPM (rpm) | 1600 |
Capacity | – |
Engine oil (l) | 9.5 |
Compressor oil (l) | 11 |
Fuel Tank (l) | 100 |
Optional extended fuel tank (l) | 30 |
Box unit dimensions | – |
Length x Width x Height (mm) | 2050 x 1200 x 1230 |
Weight (kg) | 1200 |
