Hitachi ZX17U-5 Mini Excavator
The Hitachi ZX17U-5 is a versatile excavator with adjustable width for efficient use in various applications-smooth movement in
confined spaces, as well as powerful operation in open areas
It contains a powerful engine for its size, has a minimum width of 980 mm and a rear end swing radius of 675 mm.
The machine has two travel speeds making transport through the job site more efficient and smoother. The D-Shape cross section frame is attached all around the lower end of main body. This shock-proofing feature protects the body from unexpected shocks. It’s ribbed and reinforced boom cylinder cover also provides higher impact resistance.
This model also comes with an adjustable foot crawler and blade which is adjustable from 1 280 mm to 970 mm during jobs for travelling in narrow spaces. The pin-detachable blade provides easier width adjustment.
Specifications
Model | ZX17U-5 |
|---|---|
Engine | Yanmar 3TNV70 |
Rated Power | 11.0 kW (14.8 HP) at 2 400 min (rpm) |
Maximum Torque | 50.2 Nm (5.1 kgf-m) at 1 850 min (rpm) |
Swing Speed | 8.9 min-1 (8.9 rpm) |
Travel speeds | High : 0 to 4.3 km/h
Low : 0 to 2.4 km/h |
Operating weight | 1,850 kg |
Ground pressure | 28 kPa (0.28 kgf/cm) |
Fuel tank | 19.5 L |
Maximum digging reach | 3,900mm |
Maximum digging depth | 2,170 mm |
Maximum cutting height | 3,560mm |
Maximum dumping height | 2,530mm |
Minimum swing radius (At maximum boom left swing) | 1,610mm (1,540mm) |
Blade bottom highest position above ground | 285mm |
Blade bottom lowest position above ground | 240mm |
Maximum vertical wall | 1,830mm |
Offset distance (Maximum boom-swing angle) | 420mm (50) / 650mm (70) |
